FOCUS WALL
Focus Wall has the same dimensions and lighting technology as the Focus Park and is available in the same colors.
Specifications
FOCUS WALL
Luminaire
| FOCUS WALL | |
|---|---|
| Material | Cast aluminium |
| Finish | Raw anodized |
| Graphite grey: YW355F, Akzo Nobel | |
| Silver grey: Y2370I, Akzo Nobel | |
| Corten brown: YX355F, Akzo Nobel | |
| Black textured mat: Noir 900 Sablé, SN351F, Akzo Nobel | |
| RAL by your choice | |
| Screen | Clear long-life polycarbonate with UV resistant acrylate on both sides |
| Mounting | On wall |
| Connection | In the wall box, 5 x single core AWG18-cables are included |
| Classification | cULus; Wet location; IP66; class I; IK10 (with NEMA socket IK09) |
| Corrosion class | C4, C5 optional |
| Weight | 19 lbs |
| Wind-sweeping area | 1,54 ft² |
LED
| LED type | Bridgelux COB |
|---|---|
| Operational life | min 100,000 hours at ta max 77°F (25°C), L90B10 |
| Color temperature | 2700, 3000, or 4000 Kelvin |
| Color rendering | min 80, typically 85 CRI |
| option for 90 CRI, 3000 K, with R9 = 72 | |
| OBS: longer lead times for CRI 90 | |
| Colour accuracy | 3 steps SDCM |
Driver
| Driver | Xitanium 55W 0.1-1.8A 0-10V |
|---|---|
| Inrush current | @120V; max 23 A (10% after 166,5 µs) |
| @277V; max 51,5 A (10% after 158 µs) | |
| Nominal voltage, AC | 120-277 Vac |
| Operational input voltage, AC | 108-305 Vac |
| Nominal voltage, DC | 125-250 Vdc |
| Nominal frequency range | 50-60 Hz |
| Surge protection | L/N-GND: 6 k; L-N: 6 kV |
| Operational life | min. 100,000 hours |
| Dimming/control | 0-10V |
| Other control options | via NEMA socket |
