TURN SPOT HALO Wide
Turn is a series of sleek cylindrical spotlights that can rotate and adjust to create various effects and highlight architecture.
By using several spots you can create new spaces by means of light. By combining the dramatic spot light from Turn Spot Halo and the asymmetrical light from Turn Street Halo you can enlarge the spaces designed by light without using more poles.
Specifications
TURN SPOT HALO Wide
Luminaire
| TURN SPOT HALO | |
|---|---|
| Material | Cast aluminium |
| Finish | Raw anodized |
| Graphite grey: YW355F, Akzo Nobel | |
| Silver grey: Y2370I, Akzo Nobel | |
| Corten brown: YX355F, Akzo Nobel | |
| Black textured mat: Noir 900 Sablé, SN351F, Akzo Nobel | |
| RAL by your choice | |
| Shade | Clear glass with silked edg; Honeycomb filter optional |
| Mounting | Post top/pipe: Ø3 in, Ø2,4 in with adaptor, Ø2.4-Ø3.5 in, Ø3.5-Ø4.7 inch |
| Connection | In the post, 18 ft SJTW5xAWG18, is included |
| Classification | cULus; Wet location; IP65; class I; IK8 |
| Corrosion class | C4, C5 optional |
| Weight | 12 lbs |
| Wind sweeping area | 0,57 ft² |
LED
| LED type | Bridgelux COB |
|---|---|
| Operational life | min 100,000 hours at ta max 77°F (25°C), L90B10 |
| Color temperature | 2700, 3000, or 4000 Kelvin |
| Color rendering | min 80, typically 85 CRI |
| Color accuracy | 3 steps SDCM |
Driver
| Driver | Inventronic 30W 55-1050mA |
|---|---|
| Inrush current | @120V; max 21,4 A (10% after 280 µs) |
| @277V; max 51,5 A (10% after 274 µs) | |
| Nominal voltage, AC | 100-277 Vac |
| Operational input voltage, AC | 90-305 Vac |
| Nominal voltage, DC | 127-300 Vdc |
| Nominal frequency range | 50-60 Hz |
| Surge protection | L/N-GND: 6 k; L-N: 4 kV |
| Operational life | min. 100,000 hours |
| Dimming/control | 0-10V |
| Other control options | / |
