SPACE SYMMETRIC T5

Space has an appealing and easy understandable design language, based on simplicity and interaction between form and function.

A central light source surrounded by circular elements creates a precise and harmonic composition. Transparent and calm by day, and at night - when the light is on - a wide warm and glowing scene of direct and indirect light framed by a translucent shielding.

More on the innovative solution in the video here.

Specifications

SPACE SYMMETRIC T5

Luminaire

SPACE
Material	Cast aluminium
Finish	Raw anodized
	Graphite grey: YW355F, Akzo Nobel
	Silver grey: Y2370I, Akzo Nobel
	Corten brown: YX355F, Akzo Nobel
	Black textured mat: Noir 900 Sablé, SN351F, Akzo Nobel
	RAL by your choice
Shade	Clear long-life polycarbonate with UV resistant acrylate on both sides
Mounting	Post top/pipe: Ø2,4 x h4 in or Ø3 x h2 in
Connection	In the post, 18 ft SJTW5xAWG18 (SJTW3xAWG18 for NEMA socket), is included
Classification	cULus; Wet location; IP66, class I, IK10 (with NEMA socket IK09)
Corrosion class	C4, C5 optional
Weight	22 lbs
Wind sweeping area	0.97 ft2

LED

LED	Bridgelux COB
Operational life	min 100,000 hours at ta max 77°F (25° C), L90B10
Colour temperature	2700, 3000, or 4000 Kelvin
Colour rendering	min 80, typically 85 CRI
	option for 90 CRI, 3000 K, with R9 = 72
	OBS: longer lead times for CRI 90
Colour accuracy	3 steps SDCM

Driver

Driver	Xitanium 55W 0.1-1.8A 0-10V
Inrush current	@120V; max 23 A (10% after 166,5 µs)
	@270V; max 51,5 A (10% after 158 µs)
Nominal voltage, AC	120-277 Vac
Operational input voltage, AC	108-305 Vac
Nominal voltage, DC	125-250 Vdc
Nominal frequency range	50-60 Hz
Surge protection	L/N-GND: 6 k; L-N: 6 kV
Operational life	min 100,000 hours
Dimming/control	0-10V
Other control options	via NEMA socket

Media & downloads

Product information

Brochure, SpacePDF Mounting options, SpacePDF Instructions Space SymmetricPDF Dimensions, Space with Zhaga socketsPDF Link to video with Service InstructionsPDF MaintenancePDF RoHS DeclarationPDF

3D files

Space for RevitRFA Space for ArchicadLCF Space for Ø60 post, AutocadDWG Space for Ø90 post, AutocadDWG Space for Ø60 post, 3DS3DS Space for Ø90 post, 3DS3DS Space, IFCIFC

Photos

Product image, Space symmetrical, silver greyJPG Product image, Space asymmetrical, silver greyJPG Product image, Space symmetrical, conical postJPG Product image, Space asymmetrical, conical postJPG Product image, Space, Ø60 mm post top, noir 900JPG Space, Delft, NetherlandsPDF

At 4 meter posts, Space meets P4 with 27 meters between posts. At 5 meter, P4 is met with 32 meters between posts. In both cases a path width of 3 meters.

Space is 640 mm wide, and with light broadened out into the whole housing, the luminaire is powerful and elegant at high and low posts.

Due to the innovative combination of indirect, direct, and shaded light, the Space luminaire offers comfortable human lighting in a fine balance with highly efficient and uniform lighting distributions.
